ASUS ROG Crosshair X870E Extreme E-ATX Motherboard
Original price was: ₹354,000.00.₹99,999.00Current price is: ₹99,999.00.
ASUS ROG Crosshair X870E Extreme E-ATX Motherboard
Feature
ASUS?ROG Crosshair X870E Extreme
The ROG Crosshair X870E Extreme is the flagship AMD Ryzen 9000 series motherboard, designed for the most discerning users. It provides the ultimate foundation for AM5 CPUs, DDR5 memory, and PCIe 5.0 components to ensure maximum performance and future-readiness. Its comprehensive connectivity includes USB4, and the integrated 5-inch LCD offers a unique way to monitor system performance or add a touch of personalized style.
ASUS AI CACHE BOOST
Supercharge your large language model(LLM) workflows with AI Cache Boost. Exclusive to ASUS AMD 800 Series and 600 Series motherboards using AMD Ryzen? 9000 Series Granite Ridge CPUs, this BIOS feature intelligently enhances cache efficiency, delivering up to 12.75% faster performance for your LLM tasks
AI OVERCLOCKING
Tuning is now faster and smarter than ever before
AI COOLING II
Balance the thermals and acoustics of any build with a single click
AI NETWORKING II
AI Networking II combines intelligent technologies to continuously optimize network performance, provide trustworthy and seamless connectivity, and unleash the full speed of >WiFi 7
Dynamic OC Switcher
Dynamic OC Switcher maximizes CPU performance by letting you set current and temperature thresholds to automatically switch between a manual overlock for heavy multithreaded workloads and Precision Boost Overdrive for single-threaded tasks. The latest Overclocking Load Guard has an enhanced instantaneous current protection mechanism to prevent users from experiencing system crashes during overclocking.
pcie 5.0
Fully embracing the new standard, the ROG Crosshair X870E Extreme offers abundant Gen 5 support to give unfettered bandwidth to the fastest SSDs and graphics cards available.
| Component | Details |
|---|---|
| Platform | AMD |
| Socket | AM5 |
| CPU Type | Ryzen 9000, Ryzen 8000, Ryzen 7000 |
| Chipset | X870E |
| Memory Speed | Up to 9000+ |
| Max Memory Support | 256 GB |
| Supported Memory Type | DDR5 |
| Memory Feature | Supports AMD Extended Profiles for Overclocking (EXPO?), ASUS Enhanced Memory Profile (AEMP), NitroPath DRAM Technology. * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics Port | 1 x HDMI?, 2 x USB4 |
| Expansion Slots | AMD Ryzen? 9000 & 7000 Series Desktop Processors: 2 x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8 or x8/x4/x4 modes). ** When both PCIEX16(G5)_1 and PCIEX16(G5)_2 are used, both run at x8. *** When M.2_3 is enabled, PCIEX16(G5)_1 runs at x8, PCIEX16(G5)_2 runs at x4. **** When M.2_2 and M.2_3 are enabled simultaneously, PCIEX16(G5)_2 is disabled.AMD Ryzen? 8700, 8600, 8400 Series: 2 x PCIe 4.0 x16 slots with Q-Release Slim (only PCIEX16(G5)_1 supported, total bandwidth x8, PCIEX16(G5)_2 disabled). AMD Ryzen? 8500, 8300 Series: 2 x PCIe 4.0 x16 slots with Q-Release Slim (only PCIEX16(G5)_1 supported, total bandwidth x4, PCIEX16(G5)_2 disabled). |
| Wireless Networking | WiFi 7, Bluetooth 5.4 |
| Back Panel I/O Ports | 2 x USB4? (40Gbps) Type-C, 10 x USB 10Gbps (8 x Type-A + 2 x Type-C), 1 x HDMI?, 1 x Wi-Fi Module, 1 x Realtek 5Gb Ethernet, 1 x Marvell? AQtion 10Gb Ethernet, 2 x LED-illuminated audio jacks, 1 x Optical S/PDIF out, BIOS FlashBack?, Clear CMOS. |
| Internal I/O Connector | Fan and Cooling: 1 x CPU Fan header, 1 x CPU OPT Fan header, 2 x Chassis Fan headers, 2 x Radiator Fan headers, 2 x W_PUMP+ headers, 1 x VRM Heatsink Fan header. Power: 1 x 24-pin Main Power, 2 x 8-pin +12V CPU Power, 1 x 8-pin PCIe Power. Storage: 3 x M.2 slots, 1 x DIMM.2 slot (supports 2 x M.2), 1 x SlimSAS, 4 x SATA 6Gb/s. USB: 1 x USB 20Gbps Type-C, 1 x USB 10Gbps Type-C, 2 x USB 5Gbps headers (4 ports), 2 x USB 2.0 headers (4 ports). Misc: 1 x 6-pin ARGB Gen 2 (supports 2 x ARGB Gen 2), 2 x Addressable Gen 2, Alteration PCIe mode switch, 2 x BCLK button, BIOS Switch, FlexKey, Front Panel Audio, LN2 Mode jumper, 12 x ProbeIt points, ReTry button, 2 x RSVD switches, RSVD header, Safe Boot button, Slow Mode switch, Start button, System Panel header, Thermal Sensor header, Pause switch. |
| Form Factor | E-ATX |
| Warranty | 3 Years |
| Note | Features, Price, and Specifications are subject to change without notice. Images for representation purposes only. |
| Weight | 1 kg |
|---|---|
| Product Type | Gaming |
| color | Black |
| Brands | Asus |
| Socket | AM5 |
| Memory Series | DDR5 |
| Platform | AMD |
| Motherboard Size | E-ATX |
| Warranty | 3 Years |
| EAN / UPC Code | 4711387984963 |
| Chipset | X870 |
| Motherboard Series | Asus ROG |
